Cylindrical Roller Bearing
Model List:
| Size Chart Unit: mm | Quality | Size | Axial displacement | |||||||
| Model | m»kg | d | D | B | rl | E | F | ns | ds | S |
| NN3006-K-W33 | 0.19 | 30 | 55 | 19 | 1 | 48.5 | – | 4.8 | 3.2 | 1.4 |
| NN3007-K-W33 | 0.25 | 35 | 62 | 20 | 1 | 55 | – | 4.8 | 3.2 | 1.4 |
| NN3008-K-W33 | 0.3 | 40 | 68 | 21 | 1 | 61 | – | 43 | 3.2 | 1.4 |
| NN3009-K-W33 | 0.39 | 45 | 75 | 23 | 1 | 67.5 | – | 4.8 | 32 | 1.7 |
| NN3010-K-W33 | 0.43 | 50 | 80 | 23 | 1 | 72.5 | – | 4.8 | 32 | 1.7 |
| NN3011-K-W33 | 0.63 | 55 | 90 | 26 | 1.1 | 81 | – | 4.8 | 32 | 1.9 |
| NN3012-K-W33 | 0.67 | 60 | 95 | 26 | 1.1 | 86.1 | – | 4.8 | 32 | 1.9 |
| NN3013-K-W3 | 0.72 | 65 | 100 | 26 | 1.1 | 91 | – | 4.8 | 3.2 | 1.9 |
| NNU4914-K-W33 | 0.73 | 70 | 100 | 30 | 1 | – | 80 | 4.8 | 3.2 | 1.8 |
| NN3014-K-W33 | 1.04 | 70 | 110 | 30 | 1.1 | 100 | – | 6.5 | 3.2 | 2.3 |
| NNU4915-K-W33 | 0.77 | 75 | 105 | 30 | 1 | – | 85 | 4.8 | 3.2 | 1.8 |
| NN3015-K-W33 | 1.09 | 75 | 115 | 30 | 1.1 | 105 | – | 6.5 | 3.2 | 2.3 |
| NNU4916-K-W33 | 0.81 | 80 | 110 | 30 | 1 | – | 90 | 4.8 | 3.2 | 1.8 |
| NN3016-K-W33 | 1.51 | 80 | 125 | 34 | 1.1 | 113 | – | 6.5 | 3.2 | 2.5 |
| NNU4917-K-W33 | 1.2 | 85 | 120 | 35 | 1.1 | – | 96.5 | 4.8 | 3.2 | 2 |
| NN3017-K-W33 | 1.58 | 85 | 130 | 34 | 1.1 | 118 | – | 6.5 | 3.2 | 2.5 |
| NNU4814-K-W33 | 1.26 | 90 | 125 | 35 | 1.1 | – | 101.5 | 4.8 | 3.2 | 2 |
| NN3018K-W33 | 2.05 | 90 | 140 | 37 | 1.5 | 127 | – | 6.5 | 3.2 | 2.6 |
| NNU4919-K-W33 | 1.32 | 95 | 130 | 35 | 1.1 | – | 106.5 | 4.8 | 3.2 | 2 |
| NN3019K-W33 | 2.14 | 95 | 145 | 37 | 1.5 | 132 | – | 6.5 | 3.2 | 2.6 |
| NNU4920- | 1.86 | 100 | 140 | 40 | 1.1 | – | 113 | 6.5 | 3.2 | 2 |
| NN3020-K-W33 | 2.23 | 100 | 150 | 37 | 1.5 | 137 | – | 6.5 | 3.2 | 2.6 |
| NNU4921-K-W33 | 1.93 | 105 | 145 | 40 | 1.1 | – | 118 | 6.5 | 3.2 | 2 |
| NN3021-K-W33 | 2.84 | 105 | 160 | 41 | 2 | 146 | – | 6.5 | 3.2 | 2.6 |
| NNU4922-K-W33 | 2.01 | 110 | 150 | 40 | 1.1 | – | 123 | 6.5 | 3.2 | 2 |
| NN3022-K-W33 | 3.61 | 110 | 170 | 45 | 2 | 155 | – | 6.5 | 3.2 | 2.9 |
| NNU4924-K-W33 | 2.71 | 120 | 165 | 45 | 1.1 | – | 134.5 | 6.5 | 3.2 | 2.3 |
| NN3024 K-W33 | 3.94 | 120 | 180 | 46 | 2 | 165 | – | 6.5 | 3 | 3.1 |
| NNU4926-K-W33 | 3.73 | 130 | 180 | 50 | 1.5 | – | 146 | 6.5 | 3.2 | 2.7 |
SHANDONG HAO WANT BEARING CO, LIMITED is established in 2010. We are spe-cializing in exporting angular contact ball bearing, CNC bearing, spindle bearings, motor bearing and gearbox bearing.
We own advanced production equipment and professional engineers to guarantee all the goods are perfect when our customer receive.
We devote to your trustful partner and supplier.
