FL760204/P4 DBB Flange Type Screw Ball Support Bearing
1. Specification:
| Bearing Type | Ball | |
| For Load Direction | Ball screw support | |
| Construction | Ball screw support | |
| Seal Type | Sealed | |
| Flange type | Round flange | |
| Part Number | FL760204/P4 DBB | |
| Inner diameter | 20 mm | |
| Outer diameter | 47 mm | |
| Outer ring height | 36 mm | |
| Inner ring height | 38 mm | |
| Flange thickness | 10 mm | |
| Flange diameter | 73 mm | |
| Ring Material | 52100 Chrome steel | |
| Ball Material | 52100 Chrome steel | |
| Cage Material | Nylon | |
| Lubrication | Lubricated | |
| Shaft Mount Type | Press Fit | |
Flange Ball Screw Bearing Dimension：
| model | Boundary Dimensions (mm) | Basic Load Rating (kN) | Limiting | Weight (kg) | |||||
| Speed(rpm) | |||||||||
| d | D | B | r min | Ca | Coa | grease | oil | ||
| 760201 | 12 | 32 | 10 | 0.6 | 11.6 | 12.5 | 8000 | 10000 | 0.04 |
| 760202 | 15 | 35 | 11 | 0.6 | 12.5 | 15 | 6000 | 8000 | 0.05 |
| 760203 | 17 | 40 | 12 | 0.6 | 16.6 | 20 | 6000 | 8000 | 0.075 |
| 760204 | 20 | 47 | 14 | 1 | 19.3 | 25 | 5000 | 6900 | 0.12 |
| 760304 | 20 | 52 | 15 | 1.1 | 24.5 | 32 | 4500 | 6300 | 0.17 |
| 760205 | 25 | 52 | 15 | 1 | 22 | 30.5 | 4500 | 6300 | 0.15 |
| 760305 | 25 | 62 | 17 | 1.1 | 28.5 | 41.5 | 3800 | 5300 | 0.27 |
| 760206 | 30 | 62 | 16 | 1 | 26 | 39 | 3800 | 5300 | 0.23 |
| 760306 | 30 | 72 | 19 | 1.1 | 34.5 | 55 | 3200 | 4400 | 0.4 |
| 760207 | 35 | 72 | 17 | 1.1 | 30 | 50 | 3200 | 4400 | 0.35 |
| 760307 | 35 | 80 | 21 | 1.5 | 36.5 | 61 | 3000 | 4200 | 0.55 |
| 760208 | 40 | 80 | 18 | 1.1 | 37.5 | 64 | 2800 | 3900 | 0.45 |
| 760308 | 40 | 90 | 23 | 1.5 | 50 | 83 | 2600 | 3600 | 0.75 |
| 760209 | 45 | 85 | 19 | 1.1 | 38 | 68 | 2600 | 3600 | 0.5 |
| 760309 | 45 | 100 | 25 | 1.5 | 58.5 | 104 | 2200 | 3100 | 1 |
| 760210 | 50 | 90 | 20 | 1.1 | 39 | 75 | 2400 | 3300 | 0.55 |
| 760310 | 50 | 110 | 27 | 2 | 69.5 | 127 | 2000 | 2800 | 1.3 |
| 760211 | 55 | 100 | 21 | 1.5 | 40.5 | 81.5 | 2200 | 3000 | 0.75 |
| 760311 | 55 | 120 | 29 | 2 | 78 | 146 | 1900 | 2600 | 1.7 |
| 730212 | 60 | 110 | 22 | 1.5 | 56 | 112 | 2000 | 2800 | 0.95 |
| 760312 | 60 | 130 | 31 | 2.1 | 88 | 166 | 1800 | 2500 | 2.1 |
